SSD Not Showing Up

Fix SSD Not Showing Up

SSD Not Showing Up

Can’t show you see the SSD disk on your Windows 11 PC? Are you unable to store the data due to this SSD Not Showing Up problem? Don’t worry! You can troubleshoot the issue by using the solutions given in this post.

SSD or Solid-State Drive is one kind of storage device that is used in our computers. We can store a huge amount of data on these drives.

Though it is costlier than the Hard-disk Drive (HDD), it improves computer performance. But in some cases, the SSD will not detect on the Windows devices.

There could be any reason, such as drivers are expired, the drive letter is missing, etc. To know full details about this problem, check out the following sections.



SSD Not Showing Up: Problem Overview

Solid-State Drive is one of the best options for faster read & write operations. By using SSDs, the power consumption is also lowered compared to other disks.

When we compared to traditional mechanical hard drives, SSDs are far better in terms of performance. That’s the reason why many people are choosing SSDs as storage devices.

Moreover, the people who want to protect their privacy and private data are using SSDs because it includes firmware-level encryption.

But the SSDs also trouble you like other traditional Hard-Disk Drives. One such problem that you will face most of the time is SSD Not Showing Up issue.

There are several reasons for causing this problem on our Windows computers. They are:

  • No drive letter is assigned to the SSD
  • Corrupted File System of the drive
  • Outdated device drivers
  • The memory space is not allocated to the Solid-State Drive
  • There could be initialization problems with your SSD
  • Your SSD might be corrupted or damaged fully
  • Your Windows is unable to detect the SSD
  • SSD drive is not enabled in BIOS

It could be anyone or more reasons that trigger this problem. Now, proceed to the following sections to know the methods that will solve this SSD Not Showing Up issue.



SSD Not Showing Up: Related Problems

Now, check out the following paragraphs to know various areas where you face this SSD Not Showing Up issue.



SSD Not Showing Up: Basic Troubleshooting Steps

Before going to use the basic methods, restart your Windows 11 computer and see the issue is disappeared. If not, go through the solutions given below.

  • Check for Hardware Issues

Due to the improper connection of the cable, the SSD will not show up on your computer. So, check the USB cable is properly plugged into the port.

If the SSD is still not showing, then test the cable that you’re using to confirm whether it is working or damaged. You can use the inbuilt SMART tool of Windows 11 to repair these kinds of hardware issues.

  1. Press Windows + S to open the Search Console.
    Press Windows key with letter s simultaneously
  2. Type Command Prompt -> Select CMD and right-click on it in the results section -> Choose Run as Administrator.
    Right click on the Command prompt (2)
  3. Now, type the following command and press Enter.
    1. wmic diskdrive get status.

  • If you see Status OK in the results, then execute the below steps.
  • Again open the Command Prompt with the admin permissions.
  • Type the below command and press Enter to execute it.
    1. CHKDSK [Volume [[Path] Filename]] [/F] [/V] [/R] [/X] [/C] [: size]
  • If you see nothing on your CMD, then do the following.
  • Press Windows + E -> Open the location of SSD and right-click on it -> Click Properties.
  • In the Properties window, go to the Tools tab -> Under the Error Checking section, click on the Check.
  • If you see any confirmation window, click on the OK button to grant the administrator rights.



After completing the process, restart your PC and see the SSD Not Showing Up issue is solved.

  • Verify BIOS Detects SSD

Check whether your BIOS is detecting SSD on your Windows 11 PC by going through the below instructions.

  1. First of all, reboot your Windows computer.
  2. When you see the manufacturer logo, press the F2 key on your keyboard.

Once you enter in the BIOS menu, check the SSD is listed there or not.

  • Run Hardware & Device Troubleshooter

You can also try using the inbuilt troubleshooter offered by your Windows 11. Run the Device and Hardware Troubleshooter to detect and repair the hardware issues that cause this SSD Not Detecting/Showing Up issue.

  1. Press Windows + I -> Click Update & Security.
    Choose The ‘Update And Security’ Option
  2. From the left-side pane, choose Troubleshoot tab.
  3. On the right panel, scroll down and find out the Hardware and Devices section -> Click on the Run the Troubleshooter option.

It then starts checking for the issues and repairs them automatically on your Windows 11 PC. After that, reboot the device and see the issue is solved.



Steps To Fix SSD Not Showing Up Issue

If the above solutions failed to solve the SSD Not Showing Up issue, then try the advanced troubleshooting techniques.



[ps2id id=’Step-1-Update-the-SSD-Drivers’ target=”/]

  • Step 1

Update the SSD Drivers

Even though the SSD is detected, it can’t be displayed on My Computer or This PC because of corrupted or expired drivers.

If the SSD drivers are outdated, you have to install the latest versions to view the SSD on your PC.

  1. Press Windows + X -> Select Device Manager from the menu.
  2. Expand the Disk Drives by double-clicking on it. Now, you can view all the storage devices that are connected to your computer.
    Expand the Disk Drivers option
  3. Right-click on the SSD -> Click Uninstall Device.
  4. After deleting the SSD, you need to reboot the system.

Once the system restarts, reconnect your SSD again to the PC and see the system detects the SSD normally or not.



[ps2id id=’Step-2-Initialize-New-SSD-Drive’ target=”/]

  • Step 2

Initialize New SSD Drive

Have you bought a new SSD and facing this SSD Not Showing Up? Then you need to initialize the disk first in order to access it error-freely.

If you don’t know how to initialize a new SSD, then use the instructions provided below.

  1. Press Windows + S -> Type Disk Management and select to open create and format hard disk partation.
  2. Find the drive that is not initialized. You can see it is as Unallocated.
  3. Select that drive and right-click on it -> Click on the Initialize Disk.
  4. You can see a prompt on your desktop and in that, enable the GPT (GUID Partition Table) -> Click OK.
  5. After that, you will be revert back to the previous window. Now, you can see the drive is listed as Online and Basic.

Now, try to use the SSD and check whether it shows any problem or not.



[ps2id id=’Step-3-Change-the-SSD-Drive-Letter’ target=”/]

  • Step 3

Change the SSD Drive Letter

Your SSD is not assigned with any drive letter, and that’s why it is not showing up in the file explorer. So, assign the drive letter by executing the below steps.

  1. First of all, open Disk Management on your Windows 11.
  2. Go to the Unallocated Space -> Right-click on it -> From the context menu, select the New Simple Volume.
  3. After that, click on the Next button to see the Volume Size.
  4. Click on the radio button next to the Assign the following drive letter -> From the drop-down list, choose any letter you want -> Click Next.
  5. In the next window, enable Format this volume with the following settings -> Under the File System section, choose NTFS -> Click Next to continue further.
  6. Finally, tap on the Finish button to end the process.

Once you’ve executed the steps successfully, reboot the computer and see the SSD Not Showing Up is solved.



[ps2id id=’Step-4-Format-SSD-with-NTFS’ target=”/]

  • Step 4

Format SSD with NTFS

If you still can’t see the SSD on your computer, then format SSD with NTFS, as shown below.

  1. Press Windows + R -> Type diskmgmt.msc -> Click OK.
    Press the windows key & Letter R both
  2. It opens the Disk Management window on your desktop computer.
  3. Locate the SSD that is troubling you right now and right-click on it -> Click Format.

Now, go through the on-screen steps that are displayed on your PC to finish formatting the SSD.

Note: Before going to format your SSD, use any best recovery software and restore the important files stored on your SSD to avoid data loss issues.



[ps2id id=’Step-5-Fix-Memory-Issues’ target=”/]

  • Step 5

Fix Memory Issues

If none of the solutions helped you in fixing the SSD Not Showing Up issue, then your SSD might be running out of memory space.

Insufficient memory space on your SSD is also one of the reasons for causing these issues. So, run the Windows Memory Diagnostic tool to fix the memory issues on your device.

  1. Press Windows + S -> Type Windows Memory -> Click Windows Memory Diagnostic tool shown on the results.
  2. Once the Windows Memory Diagnostic wizard opens, click on the Restart now and check for problems (recommended).
  3. Follow the steps that were shown on your screen and finish the process without any mistakes.

After completing, reboot the system and see the SSD Not Showing Up is solved.



Tips To Avoid SSD Not Showing Up

  • If you’ve disassembled your computer recently, then check the cables related to the SSD drive are connected properly.
  • Keep all your device drivers up to date in order to function the PC and all its hardware components without any issues.
  • Handle your PC or laptop carefully because even small physical damage will lead to severe problems, like the one that you’re facing right now.
  • Don’t connect corrupted or malfunctioned external drives to your PC because they will damage your SSD.



Contact Official Support

We have given all the possibilities that trigger this problem and also provided the solutions that fix it. Many users have successfully solved this SSD Not Showing Up with the above methods.

If the problem is not fixed, then visit the computer peripheral repair center. A professional technician will find and repair the issue to detect the SSD error-freely.

You need to purchase a new Solid-State Drive if none of the above solutions fix the issue. Make sure that you are buying the branded SSD drive. And initialize the SSD properly on your Windows PC to overcome these issues.



Final Words: Conclusion

To sum up everything, SSDs are cheaper than HDD and enhance computer performance. If your Windows failed to detect the SSD or did not show up the SSD, then apply the methods that were discussed in this guide.

Don’t you understand the instructions that are given above? If so, you can contact us by using the comment box. Also, you can use the comment section to share your own methods.

Provide your valuable comments on this troubleshooting guide that will help in improving our services. Hopefully, our solutions fixed the SSD Not Showing Up issue on your Windows computer.
