Kernel Mode Heap Corruption

Is Kernel Mode Heap Corruption BSOD troubling you on your Windows 10/11 PC? Then you have landed on the right post. Why because we are going to provide the solutions that troubleshoot this blue screen error.

Blue Screen of Death errors is very common for Windows users. If there is any fault with the hardware or software of your Windows PC, the screen turns blue and shows the error codes.

Kernel Mode Heap Corruption is also one such BSOD error that occurs due to wrong GPU drivers, problematic softwares, etc. Like other BSOD error codes, such as Unexpected Kernel Mode Trap, you can solve it with the tips and tricks mentioned below.

Read the following paragraphs and get to know how to fix this Kernel Mode Heap Corruption issue.


Kernel Mode Heap Corruption: Problem Overview

You know what! Kernel Mode is one of the CPU Operating Mode. Whichever processes run in this mode do not have any conditions in controlling the hardware.

But there are some hard times when the heap gets corrupted while calling on an object that is beyond the index range. Whenever it detects the corrupted heap, it will throw the Kernel Mode Heap Corruption BSOD with 0X0000013A.

On our Windows PCs, we use various third-party softwares, which are used for different purposes. In the same way, our computer is a combination of a huge number of hardware devices.

If any hardware component fails to function properly or if the softwares are not compatible with your PC, it will show the Kernel Mode Heap Corruption error code.

Users feel frustrated when they come across these blue screen errors, but they can be fixed easily when you know everything about it.

To help you in this bad situation, we are listing out the reasons that trigger the blue screen error.

  • When the graphics card drivers on your PC are expired, you can the Kernel Mode Heap Corruption error.
  • Memory leaks are also one of the reasons for it.
  • Hardware components on your PC are damaged or corrupted.
  • Problematic softwares installed on your computer.
  • Bad Windows system files

Some users say that Kernel Mode Heap Corruption occurs while starting your Windows PC. A few people are encountering the same issue when they are launching any application video game.


Kernel Mode Heap Corruption: Related Problems

Check out a few problems where you can see this Kernel Mode Heap Corruption in different areas.


Kernel Mode Heap Corruption: Basic Troubleshooting Steps

Now, let’s start with the basic methods that allow you to resolve the Kernel Mode Heap Corruption issue on your Windows PC.

  • Perform a Clean Boot

We already said in the above paragraphs that software conflicts are the major reason for causing this blue screen error. To confirm whether this problem due to startup apps, you need to perform a clean boot. For that,

  1. Press Windows + R keys on your keyboard to open the Run dialog box.
  2. Type msconfig and hit Enter.
    Type ‘Msconfig’ In The Box That Appears
  3. It opens the System Configuration window, and in that, go to the Services tab.
  4. Click on the checkbox next to the Hide all Microsoft Services option.
    Mark “Hide all Microsoft services” option.
  5. Once all the services are checked, click on the Disable All option.
    Now click on the Disable All button.
  6. Save and close the System Configuration wizard.
  7. Now, open the Task Manager by pressing Ctrl + Shift + Esc keys all at a time.
  8. Under the Startup tab, choose each application and click on the Disable button.
    select the Cloud related startup and click on disable
  9. Finally, click on the OK button and reboot the PC.

Now, check the Kernel Mode Heap Corruption BSOD appears again or not.

  • Check for Hardware Issues

This kind of blue screen error usually occurs whenever you do a few changes to your PC hardware, like installing or removing any hardware component.

For example, the problems with the RAM also trigger the Kernel Mode Heap Corruption issue. In this situation, you can use the Windows Memory Diagnostic Tool offered by your Windows Operating System.

  1. Firstly, press Windows + R -> Type mdsched.exe -> Click OK.
  2. Once the Windows Memory Diagnostic tool is opened, click on the Restart Now and Check for Problems option.
    Click on restart now and check for problems (recommended)
  3. You have to wait until the process gets finished completely.

Apart from memory issues, there are some other hardware issues that cause this kind of blue screen error. Some of them are:

  1. Make sure that all hardware components are installed perfectly on your computer.
  2. Don’t let your PC and its devices overheat.

After solving these hardware problems, check the BSOD error is fixed.


Also Read:- Machine Check Exception Windows 10: BLUE SCREEN ERROR (FIXED)


Steps To Fix Kernel Mode Heap Corruption Issue

If the above basic tricks didn’t work for you, then try out the below techniques that will resolve this Kernel Mode Heap Corruption issue.


  • Step 1

Check Event Viewer

Due to the changes made on your Windows PC, you might be seeing this blue screen error. To know which events are lead to this problem, you have to use the Event Viewer.

Event Viewer is the inbuilt component provided by Microsoft Windows in order to check out all the events that occurred on our computer.

But when you’re facing this Kernel Mode Heap Corruption problem, you cannot start your Windows normally. You need to start the PC in safe mode (All Methods) and check out those events.

  1. Restart your computer and press Del or F2 key when you see the manufacturer logo.
  2. Go to the Troubleshoot option -> Select Advanced Options and enter the Startup Settings.
  3. Once you see various Startup Settings, press the F5 key to select the Enable Safe Mode with Networking option.

After the system is booted in the Safe Mode, execute the below steps.

  1. Press Windows + R -> Type eventvwr -> Click OK.
  2. In the Event Viewer window, go to the Windows Logs tab and select System.
  3. Under this, you have to find the log that is related to the Kernel Mode Heap Corruption error.
  4. After finding it, read the description to know the cause of it and note down the Source and Event ID.

Follow further steps that you have seen on your screen and fix the issue. If you didn’t come across any such log records, then move to the next method to fix the BSOD error.


  • Step 2

Run SFC and DISM Tools

If you still struggling to solve this Kernel Mode Heap Corruption issue, run the SFC and DISM tools to find and repair the corrupted Windows system files.

  1. Press Windows + X -> Select Command Prompt (Admin) to open the CMD with the administrator permissions.

    Choose the Command Prompt (admin) option

    • Note :- If You are Windows 11 User open the Command prompt by searching on windows Search.
  2. Type the sfc /scannow command and press Enter.
    In The Command Prompt Type sfc scannow. (1)

Next, you have to run the DISM tool to restore the corrupted system files. We can use this tool when the SFC tool fails to repair the system files.

  1. Again open the Command Prompt with Admin rights.
  2. Type the two commands one by one and press Enter after typing each one.
    1. DISM.exe /Online /Cleanup-image /Scanhealth

    2. DISM.exe /Online /Cleanup-image /Restorehealth

      DISM exe Online Cleanup-image Restorehealth and press Enter

Restart your computer and check the blue screen of death error is fixed.


  • Step 3

Update or Roll Back Graphics Card Driver

Not only that but the corrupted or outdated graphics card drivers result in several issues, including the one that you are facing right now.

In case if the blue screen happens after upgrading the drivers, it means the latest drivers are not compatible with your Windows OS. So, you have to get the older drivers by using the below instructions.

  1. Press Windows + R -> Type devmgmt.msc -> Click OK.
    Enter devmgmt.msc in the Run box
  2. Expand Display Adapters -> Right-click the Graphics Card (NVIDIA or AMD or Intel) -> Click Properties.
  3. Go to the Driver tab, and click on the Roll Back Driver option.
  4. Thus, it starts installing the previously installed drivers on your PC.

If the problem happens due to expired video drivers, then upgrade them by downloading the installing the latest drivers from your GPU’s manufacturer site.


  • Step 4

Check your Graphics Card

If the Kernel Mode Heap Corruption is not solved even after upgrading or rolling back the GPU drivers, check the Graphics Card is working properly on your PC.

If the graphics card that you’re using is incompatible with your computer, then it will show these blue screen errors. At the same time, the wrong placement of the video card is also one of the reasons for it.

So, check twice whether the video card is placed correctly in the PCIe lane. If the problem occurs even though there is no issue with your GPU card, use the following tricks to fix it.


Also Read:- Kmode Exception Not Handled [Quick Troubleshooting Guide]


  • Step 5

Run Driver Verifier Manager

There could be some problem-causing drivers that were installed on your Windows 11 that is causing this Kernel Mode Heap Corruption issue.

If you want to confirm it, then access the Driver Verifier Manager included in Windows OS. By using this tool, we can get to know the problematic drivers.

  1. Firstly, boot the PC into Safe Mode.
  2. Press Windows + S -> Type CMD -> Choose Command Prompt in the results and right-click on it -> Click Run as Administrator.
  3. After that, type the verifier command and hit Enter.
  4. It immediately opens the Driver Verifier Manager window on your computer.
  5. Click on the radio button next to the Create Standard Settings -> Tap on the Next button.
  6. Now, enable the Automatically select all drivers installed on this computer -> Click on the Finish button.

By doing so, Windows starts scanning for the errors related to the drivers and restart the PC. Once the system is rebooted, you will see all the drivers that have issues.

Now, you can uninstall and reinstall them or upgrade/rollback the drivers.


  • Step 6

Uninstall Incompatible or Problematic Softwares

Have you seen this Kernel Mode Heap Corruption error after installing any new software? Yes, this could happen because of software conflicts.

To come out of this error, you have to uninstall those softwares from your computer.

  1. In order to execute the following instructions, you have to start your PC in Safe Mode.
  2. After that, press Windows + R -> Type appwiz.cpl -> Click OK.
  3. Find the software that creates conflicts and click on it.
  4. Now, tap on the Uninstall option to remove the app completely from the PC.

Once the software is uninstalled, restart the device and check the BSOD error is solved or still occurs.


Tips To Avoid Kernel Mode Heap Corruption

  • When Microsoft released the latest Windows updates, immediately install them on your PC to avoid these BSOD errors.
  • Never download and install softwares from unknown sources because they will corrupt both your OS and hardware devices.
  • Use the best driver update software to keep your system drivers up to date all the time so that you will never see these blue screen problems.
  • Don’t connect malicious or corrupted hardware components to your PC because it will damage the system files and cause many troubles.


Contact Official Support

If you are browsing this section, then you failed to fix the Kernel Mode Heap Corruption with the above methods. Don’t worry! You have some more options to overcome this blue screen problem.

Try checking out the Microsoft Communities, Reddit, and other famous forums to find some other steps that can fix it. Resetting or reinstalling Windows OS is also the best way to solve it.

Before reinstalling, save your important files and folders to cloud devices. Not only that, but you can also take help of the Microsoft Customer Support to resolve this Kernel Mode Heap Corruption issue.


Final Words: Conclusion

In the end, the blue screen of death or BSOD problems can be fixed with one or several methods. If you found any difficulty in understanding any solution, feel free to contact us.

We also welcome those users who cracked this blue screen error with their own techniques. Once you resolve this Kernel Mode Heap Corruption with our methods, provide your valuable comments.

We request you to share this troubleshooting guide with your friends and other Windows users. Want to fix any other PC or gaming issue? Then describe the problem in the comment box.

We will get in touch with you with the solutions that can solve it. Thank you for your love and support.
